Garmin

Garmin ECHOMAP UHD2 55cv Chartplotter

Écrire une critique
| poser une question

010-02592-60 2 Year Warranty

£359.95 £449.99

FAST FREE UK STANDARD SHIPPING*

• Express delivery £7.99 (Monday-Friday, orders placed before 1pm)

• Click here for more delivery information

60 DAY NO QUIBBLE RETURNS

• 60 days hassle-free returns. - exclusions apply

Description

Fish like a local with the 5″ ECHOMAP UHD2 55cv chartplotter. Get clear, high-contrast views below the boat with support for Garmin traditional and ClearVü scanning sonars (transducer sold separately). Know the waters with preloaded Garmin Navionics+ and support for Garmin Navionics Vision+.

Know the waters, catch more fish.

Preloaded Charts - Built-in Garmin Navionics+ charts or optional Garmin Navionics Vision+.

Sonar Support - With crisp, clear traditional sonar and brilliant ClearVü sonar, the fish will have nowhere to hide (transducer sold separately).

Vivid Colour Palettes - High-contrast vivid scanning sonar colour palettes make it easier than ever to distinguish targets and structure.

Add a Transducer - The ECHOMAP UHD2 device supports a variety of Garmin transducers for two types of sonar: Garmin traditional and ClearVü scanning sonars.

Wireless networking - Wirelessly share information  such as sonar, waypoints and routes with other compatible ECHOMAP UHD2 chartplotters on the boat.

ActiveCaptain App - Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, software updates, Garmin Quickdraw Community data and more.

In The Box

  • ECHOMAP Unit
  • Power / Data cable
  • 8-pin to 4-pin transducer adapter cable
  • Bail mount
  • Flush mount
  • Hardware
  • Documentation

Manual
Installation
Template

Features

o Enjoy the number one in mapping with Garmin Navionics+ and Garmin Navionics Vision+
o Bright 5″ keyed display is made for convenience
o Get double the views with Garmin CHIRP traditional and ClearVu scanning sonars (transducer sold separately)
o What's under the water looks even better with high-contrast vivid colour palettes
o Wi-Fi connectivity between compatible chartplotters makes it easy to share info

Specifications

General
o Dimensions: 18.8 x 12.2 x 6.2 cm (7.4" x 4.8" x 2.4")
o Input: Keyed
o Display Size: 10.9 x 6.6 cm (4.3" x 2.6")
o Display Resolution: 800 x 480 pixels
o Display Type: WVGA, IPS
o Weight: 0.5 kg (1.1lbs)
o Waterproof Rating: IPX7
o Mounting Options: Bail or flush

Maps & Memory
o Accepts Data Cards: 1 MicroSD Card, 32GB Max
o Waypoints: 5000
o Track Points: 50000
o Tracks: 50 Saved Tracks
o Navigation Routes: 100

Sensors
o Has Built-In Receiver: ✓
o Receiver: 5 Hz
o GPS: ✓
o Supports WAAS: ✓

Optional Map Support
o Garmin Navionics+: ✓
o Garmin Navionics Vision+: ✓
o Garmin Quickdraw Contours: ✓

Chartplotter Features
o ActiveCaptain Mobile Planning Compatible: ✓

Sonar Features & Specifications
o Displays Sonar: ✓
o Power Output: 500W
o Traditional Sonar (Dual Frequency / Beam): Built-in (Single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP
o ClearVÜ: Built-in 260/455/800 kHz

Connections
o 4-Pin Transducer Ports: 1
o Garmin Wi-Fi Network: ✓

Electrical Features
o Power Input: 9 to 18 Vdc
o Typical Current Draw at 12VDC: 1A
o Maximum Current Draw at 12VDC: 1.5A
o Maximum Power Usage at 10VDC: 18W
