Blue Sea 187 Surface Mount Circuit Breaker 200A
Écrire une critique
|
poser une question
7149-BSS 3 Year Warranty
£116.40
£130.14
Prix unitaire /
Indisponible
Free Delivery
11% de réduction
Blue Sea 187 Surface Mount Circuit Breaker 200A est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Impossible de charger la disponibilité pour le Service de retrait
FAST FREE UK STANDARD SHIPPING*
FAST FREE UK STANDARD SHIPPING*
• Express delivery £7.99 (Monday-Friday, orders placed before 1pm)
• Click here for more delivery information
60 DAY NO QUIBBLE RETURNS
60 DAY NO QUIBBLE RETURNS
• 60 days hassle-free returns. - exclusions apply
Description
Description
Provides heavy duty circuit protection for 200 Amp loads when switching and circuit protection are both required. Single lever operation - clearly visible Trip-free - cannot be held closed after trip Self-trimming case eliminates need for mounting panels or trim bezels Round case for easy installation with standard sized hole saw (panel mount) Large clearance around terminal studs accepts up to 1/0 AWG lugs Recessed mounting holes for clean appearance Robust 5 / 16"-18 terminals provide high torque connections Specifications: Interrupting Capacity: 5000A @ 12V DC, 3000A @ 24V DC, 1500A @ 42V DC Type: Thermally Responsive Bi-Metal Blade Class: Type III Switchable/Manual Reset - Trip Free Terminal Stud: 5/16" - 18 Terminal Stud torque: 75 in-lb Mounting: 1/4" Screw
