AG Tee Ball Valve with 1/4" BSP Female Ports

Scrivi una recensione
| Fai una domanda
£9.40

FAST FREE UK STANDARD SHIPPING*

• Express delivery £7.99 (Monday-Friday, orders placed before 1pm)

• Click here for more delivery information

60 DAY NO QUIBBLE RETURNS

• 60 days hassle-free returns. - exclusions apply

Descrizione

A quality Italian made, high specification ball valve. Ideal for Gas. Also suitable for hot and cold water. compressed air, pneumatic, hydraulic and most industrial fluids. Features: Quarter turn operation 100% full bore Individually Tested EN331 approved Materials: Body: Nickel plated brass CW 617N Ball: Hard chrome-plated brass CW 617N Stem: Brass CW 614N Seal: Pure Teflon (PTFE) O Rings: Viton / NBR Lever Handle: Yellow coated zinc-plated steel Fe. P04 Tee Handle: Yellow coated aluminium UNI 5076 Working Temperatures: -20 Degrees C to +60 Degrees C WARNING the formation of ice can severely damage valves & piping Technical Specification Male: BSP Taper Thread - ISO 7/1R BS21 DIN 2999 Female BSP Parallel Thread ISO 7/1R BS21 DIN 2999 (equivalent to DIN EN 10226-1 and BS EN 10266-1) Bar* - Pressure Atmosphere Kg/cm Cubed PSI* - LBS Working Pressure

Features

N/A (Not Applicable)

Specifications

o Material: Nickel Plated Brass
o Primary Construction: Brass
o Thread Connection: BSP
o Thread Fitting Size: 1/4"
o Thread Gender: Female
o Valve Design: Ball Valve
o Thread Size: 1/4" BSP Female
o Brand: AG

AG Tee Ball Valve with 1/4" BSP Female Ports - PROTEUS MARINE STORE
AG

AG Tee Ball Valve with 1/4" BSP Female Ports

£9.40
A quality Italian made, high specification ball valve. Ideal for Gas. Also suitable for hot and cold water. compressed air, pneumatic, hydraulic and most industrial fluids. Features: Quarter turn operation 100% full bore Individually Tested EN331 approved Materials: Body: Nickel plated brass CW 617N Ball: Hard chrome-plated brass CW 617N Stem: Brass CW 614N Seal: Pure Teflon (PTFE) O Rings: Viton / NBR Lever Handle: Yellow coated zinc-plated steel Fe. P04 Tee Handle: Yellow coated aluminium UNI 5076 Working Temperatures: -20 Degrees C to +60 Degrees C WARNING the formation of ice can severely damage valves & piping Technical Specification Male: BSP Taper Thread - ISO 7/1R BS21 DIN 2999 Female BSP Parallel Thread ISO 7/1R BS21 DIN 2999 (equivalent to DIN EN 10226-1 and BS EN 10266-1) Bar* - Pressure Atmosphere Kg/cm Cubed PSI* - LBS Working Pressure
